Z150, Z200 and Z300 MCBs

Used in protection against overloads and short-circuits of conductors in electric installations and protection to devices connected to those installations.

Z150 home series

* They meet the IEC 60898 standards.

* Nominal voltage: 240/415 Vac (1-pole).

* Frequency: 50/60 Hz.

* Nominal current: up to 63 A, depending on caliber.

* Tripping curve: C.

* Ambient air temperature for operation: -5 ºC to +40 ºC.

* Any mounting position.

* To be mounted on 35 mm DIN rail, or directly on plate.

* IP degree of protection: IP 20.

* Connection capacity: up to 25 mm2.

* Breaking capacity: Icu 4500 A.

Z200 industrial series

* They meet IEC 60898 standards.

* Nominal voltage: 230/400 Vac (1-pole); 400 Vac (2-poles, 3-poles and 4-poles).

* Frequency: 50/60 Hz.

* Nominal current: up to 63 A, depending on caliber.

* Tripping curve: C.

* Ambient air temperature for operation: -5 ºC to +40 ºC.

* Any mounting position.

* To be mounted on 35 mm DIN rail, or directly on plate.

* IP degree of protection: IP 20.

* Connection capacity: up to 25 mm2.

* Breaking capacity: Icu 6000 A.

Z300 industrial series

* They meet IEC 60898 standards.

* Nominal voltage: 230/400 Vac (1-pole); 400 Vac (2-poles, 3-poles and 4-poles).

* Frequency: 50/60 Hz.

* Nominal current: up to 63 A, according to caliber.

* Tripping curve: C.

* Ambient air temperature for operation: -5 ºC to +40 ºC.

* Any mounting position.

* To be mounted on 35 mm DIN rail, or directly on plate.

* IP degree of protection: IP 20.

* Connection capacity: up to 25 mm2.

* Breaking capacity: Icu 10000 A.

To download the brochure or certificate of this product, please click on our “Downloads” menu.
